ITO Coating Borosilicate Glass – Borosilicate Glass (CTE 3.3 x 10^-6 /K, 360 nm – 2.0 um); 5 – 500 ohm/sq, >85% visible transmission. No minimum order; DFM review included with every RFQ.
The point of ito coating borosilicate glass is simple: adds a patternable transparent electrode layer. We deposit it by magnetron sputtering, laser patterning option onto Borosilicate Glass and verify 5 – 500 ohm/sq, >85% visible transmission on every lot.
Key parameters
| Material | Borosilicate Glass (3.3 expansion group per ISO 3585) |
|---|---|
| Thermal expansion (CTE) | 3.3 x 10^-6 /K |
| Service temperature | 450 C continuous |
| Transmission range | 360 nm – 2.0 um |
| Density | 2.23 g/cm3 |
| Knoop hardness | 480 kg/mm2 |
| Refractive index | 1.473 @ 587 nm |
| Stock thickness | 0.50 – 30 mm |
| Maximum blank size | 600 x 400 mm |
| Treatment | ITO Coating – indium tin oxide transparent conductor |
| Specification | 5 – 500 ohm/sq, >85% visible transmission |
| Deposition / method | magnetron sputtering, laser patterning option |
| RFQ inputs | PDF/DXF/STEP drawing, quantity brackets, surface and edge spec |
Design guidance
Three items decide most of the cost and lead time on this work:
- Material note: sheet stock carries more thickness variation than float wafer stock, so lapping is often the first step.
- Sequence matters: all machining happens before ito coating; post-coating rework is not economical.
- Over-specification is the quiet budget killer: a 20/10 scratch-dig face costs roughly three times an 80/50 face, so grade each surface individually.
The full rules live in our tolerance design guide and holes and edges design guide.
What the process holds
Beyond this page, Borosilicate Glass routinely runs through lapping, coring, polishing, drilling in our shop – most real parts combine two or three of these steps.
Typical applications
The recurring buyers of ito coating borosilicate glass: medical diagnostics (flow cells, slides, microplate bottoms, cuvette windows); scientific instruments (reference flats, cells, prism mounts, stage inserts); laboratory instruments (cuvettes, sight glasses, stir-cell windows). Background reading on the underlying material science: ISO 3585 borosilicate glass 3.3.
The fastest route to a quote is geometry: use the 3D builder below, draw a dimensioned 2D drawing from it, or open the site-wide custom glass machining 3D + 2D builder for fully custom parts.
Related reading on this site: glass sandblasting, material selection guide, alkali-free glass wafers.
Frequently asked questions
Is there a minimum order for ito coating borosilicate glass?
No. Single prototypes are accepted, and pricing steps down at 10, 100 and 1,000 pieces.
How fast can prototypes ship?
Machined prototypes ship in 5 – 10 working days. Coated or bonded parts add 1 – 2 weeks depending on queue slots.
What files do you need for a quote?
A dimensioned PDF plus DXF or STEP geometry. If only a sketch exists, our drawing review service formalizes it before quoting.
Do parts ship with inspection data?
Dimensional reports, surface certificates and material certs per melt are available; specify the level on the RFQ.
What tolerances are achievable on Borosilicate Glass parts?
Ground features hold +/-0.01 mm and lapped thickness reaches +/-0.003 mm. Sheet stock carries more thickness variation than float wafer stock, so lapping is often the first step.
Specifications on this page were last reviewed by our engineering team in September 2026.
