Model: HB-Cell.
Overview
17.5ml Sample Cell Round Bottom 45*12.5*52.5mm Quartz Glass Cuvette is an optical cuvette made from Glass. Temperature 1100 Degree. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Model NO. | HB-Cell |
| Reactant State | Liquid |
| Color | Clear |
| Surface | Fire Polishing |
| Wall Thickness | 0.5-50mm |
| Processing Technology | Polishing/Grinding |
| Working Temperature | 1100 Degree |
| Density | 2.2g/cm3 |
| OEM/ODM | Yes |
| Product Name | Q108 Quartz Cuvette |
| Outside Dim H×W×D | 45*12.5*52.5mm |
| Path length | 50mm |
| Inside Width | 10mm |
| Volume | 17.5ml |
| Supplier | LIANYUNGANG BAIBO NEW MATERIAL CO., LTD. |
Technical data
| Outside Dim H×W×D mm | Path length mm | Inside Width mm | Volume ml | Product Number | ||
| ES Quartz Glass 190nm-2500nm | IR Quartz Grass 250nm-3500nm | IR Quartz Grass 250nm-3500nm | ||||
| 45*12.5*3.5 | 1 | 10 | 0.35 | Q-101 | I-101 | G-101 |
| 45*12.5*4.5 | 2 | 10 | 0.7 | Q-102 | I-102 | G-102 |
| 45*12.5*7.5 | 5 | 10 | 1.7 | Q-103 | I-103 | G-103 |
| 45*12.5*12.5 | 10 | 10 | 3.5 | Q-104 | I-104 | G-104 |
| 45*12.5*22.5 | 20 | 10 | 7 | Q-105 | I-105 | G-105 |
| 45*12.5*32.5 | 30 | 10 | 10.5 | Q-106 | I-106 | G-106 |
| 45*12.5*42.5 | 40 | 10 | 14 | Q-107 | I-107 | G-107 |
| 45*12.5*52.5 | 50 | 10 | 17.5 | Q-108 | I-108 | G-108 |
| 45*12.5*102.5 | 100 | 10 | 35 | Q-109 | I-109 | G-109 |
| 1. High-quality products | 2. Optimal price | 3.SafeTransportation |
| 4. Sample service | 5. Customized size | 6. Compensate for broken goods |
| 7. Safe package | 8. Transportation safety | 9. Low procurement risk |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass (soda-lime, borosilicate, quartz) because it fixes UV transmission and chemical resistance.
- Dimensions — listed as “0.5-50mm”; give dimensions and tolerances.
- Surface and edges — listed as “Fire Polishing”; state edge finish and any frosted or coated areas.
- Cleanliness and packing — state cleanliness level and packing for lab use.
Engineering guides for this part
For material grades and coating options, see JGS1 Quartz Glass for UV Optical and Precision Components. For an application example, read Custom Precision Glass for Microfluidic and Biomedical Devices.
FAQ
What is the 17.5ml Sample Cell Round Bottom 45*12.5*52.5mm Quartz Glass Cuvette made of? expand_more
It is listed as Glass. Other grades can be quoted if your application needs different transmission, thermal or chemical properties.
What should I include in a quote request? expand_more
Include material, dimensions, surface and edges and cleanliness and packing, plus quantity and a drawing if the part is custom.
