Application: Electronics & Instruments. Model: M1.
Overview
The 4mm Wave Textured Ultra Clear Tempered Glass with Drilled Holes for Lamp is supplied as a drilled / perforated glass plate. Listed geometry: size Customized, thickness 1.1mm, 2.2mm 0.7mm 0.5mm, flat shape. Optical / electrical data: transmittance 85% or Others, sheet resistance 7ohm, 8ohm 10ohm 14ohm…. Flatness High Class. Listed for Electronics & Instruments applications. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Shape | Flat |
|---|---|
| Size | Customized |
| Thickness | 1.1mm, 2.2mm 0.7mm 0.5mm |
| Transmittance | 85% or Others |
| Flatness | High Class |
| Usage | Electronics & Instruments |
| Model NO. | M1 |
| Appearance | Flat Tempered |
| Standard | GB/T 9963-1998 |
| Steel Degree | Tempered Glass |
| Thickness of Flat Tempered Glass | 0.3-2.2mm |
| Thickness of Curve Tempered Glass | 0.3-2.2mm |
| Fragment State | Tempered |
| Technics | Chemical Tempered |
| Resistance | 7ohm, 8ohm 10ohm 14ohm… |
| Texture | Customized |
| Max.size | 3660*2440mm |
| Max. Size | 3500*1600mm |
| Supplier | DONGGUAN SAIDA GLASS CO.,LTD |
Technical data
| Product Type | Tempered Glass 4mm Wave Textured Ultra Clear with Drilled Holes for Panel Lamp Glass |
|---|---|
| Raw Material | Crystal White/Soda Lime/Low Iron Glass |
| Size | Size can be customized |
| Thickness | 0.33-12mm |
| Tempering | Thermal Tempering/Chemical Tempering |
| Edgework | Flat Ground (Flat/Pencil/Bevelled/Chamfer Edge are available) |
| Hole | Round/Square (Irregular hole are available) |
| Color | Black/White/Silver (up to 7 layers of colors) |
| Printing Method | Normal Silkscreen/High Temperature Silkscreen |
| Coating | Anti-Glaring Anti-Reflective Anti-Fingerprint Anti-Scratches |
| Production Process | Cut-Edge Polish-CNC-Clean-Print-Clean-Inspect-Pack |
| Features | Anti-scratches/Waterproof/anti-fingerprint/anti-fire/easy to clean/high-pressure scratch resistant |
| Keywords | Anti Fingerprints Flat Switch Glass Panel Easy Clean-up Switch Glass Panel Intelligent Touch Switch Tempered Glass Panel |
| Automatic Cutting Machine | Max.size:3660*2440mm |
|---|---|
| CNC | Max.size: 2300*1500mm |
| Edge Grinding & Chamfering | Max.size: 2400*1400mm |
| Automatic Production Line | Max.size :2200*1200mm |
| Thermal Tempered Furnace | Max. Size:3500*1600mm |
| Chemical Tempered Oven | Max. Size: 2000*1200mm |
| Coating Line | Max. Size:2400*1400mm |
| Dry Oven Line | Max. Size : 3500*1600mm |
| Packaging Line | Max. Size: 3500*1600mm |
| Automatic Cleaning Machine | Max. Size: 3500*1600mm |
What to specify when you request a quote
- Material — name the glass or quartz grade.
- Outline and thickness — listed as “Customized”; give outline, thickness and tolerances.
- Holes, slots and features — listed as “Flat”; dimension every hole and its position tolerance on the drawing.
- Edges — state edge finish and chamfer.
- Surface — listed as “High Class”; state polish and flatness where they matter.
