Application: Beam Dispersion, Beam Split.
Overview
Advanced Optical Pentaprisms for Superior Light Control: an optical prism. It is used in Beam Dispersion and Beam Split. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Usage | Beam Dispersion, Beam Split |
|---|---|
| Appearance Quality | 20-10 |
| Angle | 2'' |
| Aperture | 1-5 |
| Supplier | Crystrong Photonics Technology Co., Ltd. |
What to specify when you request a quote
- Material — name the glass or crystal.
- Geometry — listed as “2''”; give diameter, focal length or radii, angles and tolerances.
- Surface figure — quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — list the band and reflectance or transmission target.
