Product type: Pentagonal Prism. Application: Beam Dispersion. Model: FSOP.
Overview
Bk7 Optical Glass Beam Splitting Prisms Penta Prism for Spectroscopy is an optical prism made from Glass. Listed geometry: pentagonal prism shape. Surface quality 20/10 or Better. Listed for Scientific Research applications. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Type | Pentagonal Prism |
| Shape | Pentagonal Prism |
| Surface Quality | 20/10 or Better |
| Clear Aperture | >90% |
| Application | Scientific Research |
| Usage | Beam Dispersion |
| Model NO. | FSOP |
| Model No | Fsop-7 |
| Principle | Ar Coating |
| Supplier | Tianjin Fushi Optical Technology Co., Ltd. |
Technical data
| PRODUCT NAME | Pentagonal Prism |
|---|---|
| PRODUCT SIZE | 1-500mm |
| SURFACE PERFECTION | 20/10 or better |
| DIMENSIONAL TOLERANCE | ±0.02MM |
| MATERIAL | Glass |
| TRANSMITTANCE | 96% |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “20/10 or Better”; quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — list the band and reflectance or transmission target.
Engineering guides for this part
How parts like this are machined and finished is covered in Flat Glass Polishing Process for Precision Substrates. Before sending a drawing, check Design Guide for Holes, Slots, and Edges in Custom Glass Parts.
FAQ
What is the Bk7 Optical Glass Beam Splitting Prisms Penta Prism for Spectroscopy made of? expand_more
It is listed as Glass. Other grades can be quoted if your application needs different transmission, thermal or chemical properties.
Where is this optical prism used? expand_more
Listed applications: Scientific Research.
What should I include in a quote request? expand_more
Include material, geometry, surface figure, centring and edges and coating, plus quantity and a drawing if the part is custom.
