Product type: Prism. Application: Lighting, Medical, Optical, Photography. Model: optical glass 300mm prism.
Overview
High-Precision Prisms (within 300mm) , Optical Glass (FK61, K9, BK7, etc.): an optical prism made from Optical Glass. Optical / electrical data: transmittance Customized. Coating: Customized. Listed for Lighting, Medical, Optical and Photography applications. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass |
|---|---|
| Type | Prism |
| Shape | Customized |
| Transmittance | Customized |
| Coating | Customized |
| Usage | Lighting, Medical, Optical, Photography |
| Model NO. | optical glass 300mm prism |
| Lenses Color | Customized |
| Supplier | Hesy. Co., Ltd |
Technical data
| Dimension range | 5-150mm |
|---|---|
| Angular tolerance | 2” |
| Surface Flatness | PV<λ/10,RMS<λ/200(λ=632.8nm) |
| Surface Quality | Grade Ⅰ-Ⅴ |
| Materials | H-K9L,fused silica and other optical materials |
| Adhesive material | NorlandUV optically clear adhesive NOA61 |
What to specify when you request a quote
- Material — listed as “Optical Glass”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “Customized”; list the band and reflectance or transmission target.
