Product type: Color Filter. Application: Optical, High Near-Infrared Transmittance,Automotive. Model: BP850/30K.
Overview
High Temperature Resistant Customization 850nm IR Optical Bandpass Filter: a bandpass filter made from Optical Glass. Listed geometry: size Customizable, thickness 5mm-10mm. Optical / electrical data: wavelength 850 ± 3 Nm, bandwidth 30 ± 3 Nm, transmittance ≥ 90%. Surface quality 60/40. Typical applications: Optical, High Near-Infrared Transmittance and Automotive. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass |
|---|---|
| Type | Color Filter |
| Shape | Customized |
| Size | Customizable |
| Surface Quality | 60/40 |
| Usage | Optical, High Near-Infrared Transmittance,Automotive |
| Thickness Range | 5mm-10mm |
| Model NO. | BP850/30K |
| Color | Custom |
| Angle of incidence | 0° |
| Product Name | Nir 850nm Filter |
| Central Wavelength (Cwl) | 850 ± 3 Nm |
| Fwhm Bandwidth | 30 ± 3 Nm |
| Blocking Range | 200 – 1100 Nm |
| Optical Density (Od) | ≥ Od4 |
| Peak Transmittance (Tpeak) | ≥ 90% |
| Supplier | Shanghai Mega-9 Optoelectronic Co., Ltd. |
Technical data
| Product Name | NIR 850nm Filter |
|---|---|
| Keywords | Bandpass Filter |
| Central Wavelength (CWL) | 850 ± 3 nm |
| FWHM Bandwidth | 30 ± 3 nm |
| Blocking Range | 200 – 1100 nm |
| Optical Density (OD) | ≥ OD4 |
| Peak Transmittance (Tpeak) | ≥ 90% |
| Angle of Incidence (AOI) | 0° |
| Size | Customizable |
| Surface Quality | 60/40 |
What to specify when you request a quote
- Spectral target — listed as “850 ± 3 Nm”; state the centre or edge wavelength, the bandwidth and the minimum transmission in the passband.
- Blocking — listed as “200 – 1100 Nm”; give the blocking range and optical density (OD) the system needs.
- Angle of incidence — listed as “0°”; interference filters shift with angle, so specify the operating angle and cone.
- Size and thickness — listed as “Customizable”; give outline, thickness and tolerance, and whether the filter is mounted.
- Substrate — listed as “Optical Glass”; name the substrate glass if thermal or UV behaviour matters.
- Surface quality — listed as “60/40”; quote scratch-dig for imaging paths.
