Product type: Equilateral Prism. Application: Beam Dispersion. Model: Fsop-5.
Overview
K9 Bk7 Equilateral Prism Triangular Prismcustomizableoptical Prism is an optical prism made from Glass. Listed geometry: long prism shape. Surface quality 20/10 or Better. Typical applications: Digital Device. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Type | Equilateral Prism |
| Shape | Long Prism |
| Surface Quality | 20/10 or Better |
| Clear Aperture | >90% |
| Application | Digital Device |
| Usage | Beam Dispersion |
| Model No | Fsop-5 |
| Principle | Ar Coating |
| Supplier | Tianjin Fushi Optical Technology Co., Ltd. |
Technical data
| PRODUCT NAME | Equilateral Prism |
|---|---|
| PRODUCT SIZE | 1-500mm |
| SURFACE PERFECTION | 20/10 or better |
| DIMENSIONAL TOLERANCE | ±0.02MM |
| MATERIAL | Glass |
| TRANSMITTANCE | 96% |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “20/10 or Better”; quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — list the band and reflectance or transmission target.
Engineering guides for this part
How parts like this are machined and finished is covered in Optical Glass Polishing for High Clarity Surfaces. Before sending a drawing, check Design Guide for Holes, Slots, and Edges in Custom Glass Parts.
FAQ
What is the K9 Bk7 Equilateral Prism Triangular Prismcustomizableoptical Prism made of? expand_more
It is listed as Glass. Other grades can be quoted if your application needs different transmission, thermal or chemical properties.
Where is this optical prism used? expand_more
Listed applications: Digital Device.
What should I include in a quote request? expand_more
Include material, geometry, surface figure, centring and edges and coating, plus quantity and a drawing if the part is custom.
