Product type: Bandpass Filter. Application: Medical, Optical, Industrial. Model: 21010103451.
Overview
Mega-9 High Transmittance 1550nm Round Glass Bandpass Optical Filter for Medical: a bandpass filter made from Glass. Listed geometry: thickness 5mm-10mm, round shape. Optical / electrical data: wavelength 1550nm, bandwidth 10nm, transmittance >90%. It is used in Medical, Optical and Industrial. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Type | Bandpass Filter |
| Shape | Round |
| Usage | Medical, Optical, Industrial |
| Model NO. | 21010103451 |
| Thickness Range | 5mm-10mm |
| Color | No |
| Principle | Interference |
| Angle of incidence | 0° |
| Central Wavelength | 1550nm |
| Bandwidth | 10nm |
| Blocking Range | 800-2000nm |
| Blocking Depth | Od4 |
| Peak Transmittance | >90% |
| Center Wavelength (CWL) | Precisely positioned with a customization accuracy of up to ±0.25nm to ensure perfect matching with the emission spectrum of light sources and detector sensitivities. |
| Peak Transmittance (Tpeak) | High-transmission dielectric coating with typical peak transmittance >90% (up to >95% for specific bands), maximizing the retention of the effective signal light. |
| Bandwidth (FWHM) | Available in a wide range of options, from ultra-narrow band (<3nm), narrow band (3-20nm) to broadband (>20nm), catering to different spectral resolution requirements. |
| Warranty Period | 2 Years |
| Technology | Free technical support and solutions provided |
| Supplier | Shanghai Mega-9 Optoelectronic Co., Ltd. |
Technical data
| Parameter | BP1064/1K | BP532/1K | BP632/1K |
| Center Wavelength (nm) | 1064 ± 0.15 | 532 ± 0.15 | 632 ± 0.15 |
| Bandwidth (FWHM, nm) | 1.0 ± 0.2 | 1.0 ± 0.2 | 1.5 ± 0.2 |
| Peak Transmittance (%) | ≥70 | ≥ 75 | ≥ 80 |
| Blocking Depth (OD) | OD5 | OD6 | OD6 |
| Surface Quality (S/D) | 60-40 | 60-40 | 60-40 |
| Operating Temp. (°C) | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 |
| Dimensions (mm) | 25.4 *1.0 | 25.4 *1.0 | 25.4 *1.0 |
What to specify when you request a quote
- Spectral target — listed as “1550nm”; state the centre or edge wavelength, the bandwidth and the minimum transmission in the passband.
- Blocking — listed as “800-2000nm”; give the blocking range and optical density (OD) the system needs.
- Angle of incidence — listed as “0°”; interference filters shift with angle, so specify the operating angle and cone.
- Size and thickness — listed as “5mm-10mm”; give outline, thickness and tolerance, and whether the filter is mounted.
- Substrate — listed as “Glass”; name the substrate glass if thermal or UV behaviour matters.
- Surface quality — quote scratch-dig for imaging paths.
