Product type: Wedge Prism. Application: Beam Dispersion, Beam Split, Laser, Astronomy, Imaging, Detection, etc. Model: OP-0016.
Overview
Optical Glass Wedge Prism N-Bk7 K9 Glass Wedge Prism with Ar Coating Custom Prism: an optical prism in Glass (Uvfs/Sf10/N-Lakl21, Equivalent substrate). Listed geometry: pentagonal prism shape. Supplied uncoated; surface quality 40-20 Scratch-Dig or Custom Manufacturing; flatness Lambda/10 at 632.8 Nm Over The Clear Aperture. It is used in Medical Instrument. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Substrate | Uvfs/Sf10/N-Lakl21, Equivalent |
| Type | Wedge Prism |
| Shape | Pentagonal Prism |
| Surface Quality | 40-20 Scratch-Dig or Custom Manufacturing |
| Application | Medical Instrument |
| Usage | Beam Dispersion, Beam Split, Laser, Astronomy, Imaging, Detection, etc |
| Model NO. | OP-0016 |
| Surface Flatness | Lambda/10 at 632.8 Nm Over The Clear Aperture |
| Coating Type | Uncoated |
| Supplier | C-Laser (Taicang) Material Technology Co., Ltd. |
Technical data
| Product Name | Wedge prism |
|---|---|
| Material | optical glass |
| Color | Transparent |
| Dimension Tolerance | ±0.01mm |
| Thickness Tolerance | ±0.01~0.1mm |
| Angle Tolerance | 3''~5'' |
| Surface Quality | 60/40,40/20 |
| Coating | AR coating/custom |
| Used | digital equipment, science and technology, medical equipment and other fields |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “40-20 Scratch-Dig or Custom Manufacturing”; quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “Uncoated”; list the band and reflectance or transmission target.
