Application: Microscope Slide. Model: TYI-7101.
Overview
Polished Edges 1inch by 3inch Plain Lab Glassware Glass Slide Microscope Slides 7101: a microscope slide / cover slip made from Rubber / Plastic. Listed geometry: size 1inchx3inch/25.4X76.2mm*1-1.2mm, thickness 1mm. Typical applications: Microscope Slide. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Rubber / Plastic |
|---|---|
| Size | 1inchx3inch/25.4X76.2mm*1-1.2mm |
| Thickness | 1mm |
| Usage | Microscope Slide |
| Model NO. | TYI-7101 |
| Polishing | Polishing |
| Quantity | Complex |
| Cleaning | Be Cleaned |
| Product Name | Microscope Slides 7101 |
| Feature | Polished Edges |
| https | //cnwtc2.en.made-in-china.com/product/zZdfPKxgYQkr/China-Medical-Disposables-Products-Nylon-Flocked-Swabs-Rapid-Test-Dental-Swab.html |
| Supplier | Chongqing New World Trading Co., Ltd. |
Technical data
| Model | Size | Thickness | Description | Packing |
| TYI-7101-A | 25.4×76.2(1''x3'') | 1.0-1.2mm | Plain, Polished Edges | 50pcs/box or 72pcs/box |
| TYI-7101-B | 25.4×76.2(1''x3'') | 1.0-1.2mm | Plain, Polished Edges | 50pcs/box or 72pcs/box |
| TYI-7102 | 25.4×76.2(1''x3'') | 1.0-1.2mm | Plain, Cut Edges | 50pcs/box or 72pcs/box |
| TYI-7105 | 25.4×76.2(1''x3'') | 1.0-1.2mm | Polished Edges,Single Frosted End | 50pcs/box or 72pcs/box |
| TYI-7107 | 25.4×76.2(1''x3'') | 1.0-1.2mm | Polished Edges,Double Frosted End | 50pcs/box or 72pcs/box |
| TYI-7109 | 25.4×76.2(1''x3'') | 1.0-1.2mm | Clear glass, Polished Edges, Single Frosted End | 50pcs/box or 72pcs/box |
| TYI01 | 25.4×76.2(1''x3'') | 1.0-1.2mm | Adhesion Slide, Positive Charged | 50pcs/box or100pcs/box |
What to specify when you request a quote
- Material — listed as “Rubber / Plastic”; name the glass (soda-lime, borosilicate, quartz) because it fixes UV transmission and chemical resistance.
- Dimensions — listed as “1inchx3inch/25.4X76.2mm*1-1.2mm”; give dimensions and tolerances.
- Surface and edges — listed as “Polishing”; state edge finish and any frosted or coated areas.
- Cleanliness and packing — listed as “Be Cleaned”; state cleanliness level and packing for lab use.
