Application: Medical, Civil, Labs. Model: Reflective Mirror.
Overview
The Round Half Mirror Glass Splitter for Optical Instrument is supplied as a beam splitter made from Glass. Listed geometry: diameter Customized, thickness Customized. Listed for Medical, Civil and Labs applications. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Shape | Customized |
| Diameter | Customized |
| Thickness | Customized |
| Application | Medical, Civil, Labs |
| Model NO. | Reflective Mirror |
| Color | Customized |
| Supplier | Huizhou Shengquan Optical Glass Products Co. Ltd |
Technical data
| Size | customized |
|---|---|
| Thickness | 1.5mm or customized |
| Surface Quality | 40/20 |
| Transmission | >85% |
| Parallelism | <5 arcsec |
| Flatness | L/4 |
What to specify when you request a quote
- Split ratio — give the R/T ratio and its tolerance.
- Wavelength and polarisation — state the band and whether the split must be polarising or non-polarising.
- Angle of incidence — plate splitters are usually used at 45°; give the actual angle.
- Size and geometry — listed as “Customized”; give cube edge or plate size, thickness and wedge if any.
- Surface quality and flatness — quote transmitted wavefront for imaging systems.
Engineering guides for this part
For material grades and coating options, see Dichroic Filter Glass: Selecting Substrates for Precision Optical Separation. For an application example, read Dichroic Filter Glass for Smart Appliance Lighting Modules. A related standard product is Laser Beam Splitter Glass Sheet.
FAQ
What is the Round Half Mirror Glass Splitter for Optical Instrument made of? expand_more
It is listed as Glass. Other grades can be quoted if your application needs different transmission, thermal or chemical properties.
What sizes and thicknesses are available? expand_more
The listing gives diameter Customized, thickness Customized. Custom outlines and thicknesses are made to drawing; state the tolerance you need.
Where is this beam splitter used? expand_more
Listed applications: Medical, Civil and Labs.
What should I include in a quote request? expand_more
Include split ratio, wavelength and polarisation, angle of incidence, size and geometry and surface quality and flatness, plus quantity and a drawing if the part is custom.
