Product type: Clear Quartz Pipe. Application: Heating Tube Furnace Tube. Model: TJ-0008084.
Overview
Slotted Quartz Tube Customized Quartz Tube Quartz Glass Tube: a precision glass tube / rod made from Quartz Glass. Listed geometry: twin tube shape. It is used in Heating Tube Furnace Tube. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Type | Clear Quartz Pipe |
|---|---|
| Shape | Twin Tube |
| Application | Heating Tube Furnace Tube |
| Model NO. | TJ-0008084 |
| Color | Transparent |
| Materials | Quartz Glass |
| Softening Point | 1680℃ |
| Purity | 99.99% |
| Density | 2.2g/cm3 |
| Ozone Content | Ozone Free |
| Annealing Point | 1210℃ |
| Surface Treatment | Polished |
| Strain Point | 1120℃ |
| Outside Diameter | 2-500mm |
| Supplier | Donghai County Tengjun Quartz Products Co., Ltd. |
Technical data
| Compressive strength | >1100Mpa | Coefficient of thermal expansion | 5.5×10-7cm/cm. |
| Bending Strength | 67Mpa | Melting temperature | 1750~1800 |
| Tensile Strength | 48.3Mpa | The temperature for a short time | 1500 |
| Poisson's Ratio | 0.14~0.17 | The temperature for a long time | 1200° to 1300 |
| Elastic Modulus | 71700Mpa | Resistivity | 7×107.2.cm |
| Shearing Modulus | 31000Mpa | Dielectric Strength | 250~400Kvicm |
| Moh's Hardness | 5.3~6.5(Moh's Scale) | Dielectric Constant | 3.7~3.9 |
| Deformation Point | 1650 | Dielectric absorption coefficient | <4×104 |
| Specific Heat(20~350°) | 670J/kg | Dielectric loss coefficient | <1×104 |
| Thermai Conductivity | 1.4W/m | Pervious to light performance | 80%-95% |
What to specify when you request a quote
- Material — listed as “Quartz Glass”; name the glass (borosilicate 3.3, quartz, soda-lime).
- OD, ID and wall — listed as “TJ-0008084”; give outer and inner diameter or wall and their tolerances.
- Length and ends — give length, end finish and any closed or flared ends.
- Straightness and bore — state straightness and bore tolerance for precision tubing.
