Product type: Cylindrical Glass Lens. Application: Lighting, Medical, Optical, Photography. Model: KGO108.
Overview
The Synthetic UV Fused Silica Bi-Convex Optical Glass Plane Lens with Ar Coating is supplied as an optical lens made from Fused Silica,Bk7,B270. Optical / electrical data: transmittance >95%. Coating: Polishing, Coating. Typical applications: Lighting, Medical, Optical and Photography. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Fused Silica,Bk7,B270 |
|---|---|
| Type | Cylindrical Glass Lens |
| Transmittance | >95% |
| Coating | Polishing, Coating |
| Usage | Lighting, Medical, Optical, Photography |
| Model NO. | KGO108 |
| Lenses Color | Clear |
| Supplier | Nanyang Kylin Special Glass Co., Ltd. |
Technical data
| Material | K9,fused silica,etc. |
|---|---|
| Focal length | ±2% |
| Dimension tolerance | +0/-0.1mm |
| Center thickness | ±0.1mm |
| Centration | 3' |
| Surface quality | 60/40 |
| Clear aperture | 90% |
What to specify when you request a quote
- Material — listed as “Fused Silica,Bk7,B270”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “Polishing, Coating”; list the band and reflectance or transmission target.
