Application: Observing Liquid Levels in Boiler.
Overview
Tempered Borosilicate Glass Disc Borosilicate Level Guage Glass is a precision glass plate / sheet made from Glass. Listed geometry: flat strip shape. Typical applications: Observing Liquid Levels in Boiler. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Shape | Flat Strip |
| Application | Observing Liquid Levels in Boiler |
| Head Code | Round |
| Connection | Gasket |
| Color | Clear |
| Feature | Heat Resistant, High Pressure Resistant |
| Processing | Grinding, Tempering |
| Toughen | Tempered |
| Supplier | Jinan JSV Industrial Co., Ltd. |
Technical data
| Product Name | Gauge Glass, Sight Glass | |
| Material | Borosilicate glass, quartz glass, soda lime glass | |
| Shape | Tubular, flat, round, strip | |
| Packing | Carton, pallet, wooden crate | |
| Dimension |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass or quartz grade.
- Outline and thickness — give outline, thickness and tolerances.
- Holes, slots and features — listed as “Flat Strip”; dimension every hole and its position tolerance on the drawing.
- Edges — state edge finish and chamfer.
- Surface — state polish and flatness where they matter.
