Product type: All Types. Application: Lighting, Medical, Optical, Photography, Laser System. Model: RAY-OM110#.
Overview
The Ultra Big Size Quartz/Silicon/Sapphire Ingot CNC Multi-Wire Saw Cutting Serivce is supplied as a shaped glass part made from Optical Glass/Fused Silica/Borosillice Glass/CaF2. Listed geometry: all shapes shape. Optical / electrical data: transmittance as Per The Demand. Coating: Polishing/Coating/Uncoating, etc. It is used in Lighting, Medical, Optical, Photography and Laser System. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass/Fused Silica/Borosillice Glass/CaF2 |
|---|---|
| Type | All Types |
| Shape | All Shapes |
| Transmittance | as Per The Demand |
| Coating | Polishing/Coating/Uncoating, etc |
| Usage | Lighting, Medical, Optical, Photography, Laser System |
| Model NO. | RAY-OM110# |
| Lenses Color | Clear |
| Machining Materials Type I | Quartz/Silicon/Sapphire Ingot/Graphite |
| Machining Materials Type II | Fused Slica/Sic/CaF2/Baf2/Zns/Znse |
| Max.Cutting Size | D1000mm*500mm |
| Max.Cutting Thickness | 500mm |
| Cutting Accuracy | 0.05mm |
| Custom Manufacturing Capacity 2 | Ultra big size Quartz/Silicon/Sapphire Ingot CNC Multi-Wire Saw Cutting |
| Main Processing Technical Capacity Data | I |
| Max. Cutting Size Range | D1000mm |
| Slice Parallelism | 0.015mm |
| ain Cutting Technologies Characters | 1).Cutting bending (bow) is small |
| ain Cooperation Materials Manufacturers | CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC |
| Supplier | Shanghai Rui Tai Photoelectric Technology Co., Ltd. |
Technical data
| Items | Value |
|---|---|
| Max. Cutting Size Range: | D1000mm |
| Max. Cutting Thickness | 500mm |
| Max. Loading Weight | 1200kg |
| Cutting Surface Roughness | ≤0.2mm |
| Cutting Accuracy | ≤0.05mm |
| Max. Cutting Efficiency | 30mm/h |
| Slice Thickness | ≥400um |
| Slice Parallelism: | 0.015mm |
What to specify when you request a quote
- Material — listed as “Optical Glass/Fused Silica/Borosillice Glass/CaF2”; name the glass or quartz grade.
- Outline and thickness — listed as “D1000mm*500mm”; give outline, thickness and tolerances.
- Holes, slots and features — listed as “All Shapes”; dimension every hole and its position tolerance on the drawing.
- Edges — state edge finish and chamfer.
- Surface — state polish and flatness where they matter.
