Product type: Optical Lens. Application: Lighting, Medical, Optical, Photography, Laser, Astronomy, Imaging, Detection, etc. Model: RAY-XS079#.
Overview
Advanced Smart Light Control Optical Lens Wedge Window System is an optical lens in Optical Glass (UV Fused Silica substrate). Listed geometry: thickness 1.0mm-6.0mm, 9.4mm or Custom Manufacturing, single-lens shape. Optical / electrical data: transmittance >95%. Coating: Hard Refractory Coating or Uncoating; surface quality 15-5 Scratch-Dig or Custom Manufacturing. It is used in Lighting, Medical, Optical, Photography and Laser. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass |
|---|---|
| Substrate | UV Fused Silica |
| Type | Optical Lens |
| Shape | Single-lens |
| Thickness | 1.0mm-6.0mm, 9.4mm or Custom Manufacturing |
| Transmittance | >95% |
| Coating | Hard Refractory Coating or Uncoating |
| Surface Quality | 15-5 Scratch-Dig or Custom Manufacturing |
| Usage | Lighting, Medical, Optical, Photography, Laser, Astronomy, Imaging, Detection, etc |
| Model NO. | RAY-XS079# |
| Lenses Color | Clear |
| Wedge | 30 (+-)15 Arc Min |
| Ar.Coating | Uncoating, or 430-700nm/650-1000nm/1000-1550nm |
| Lens Substrates | UV fused silica |
| Optional I | UV fused silica |
| Optional II | Equivalent UV fused silica |
| Main Applying | 1).Mainly used as vacuum window, convection grating or interferometer compensation plate. |
| Main Optical Tech Specification | Lens Shape |
| Main Cooperation Materials Manufacturers | CORNING, OHARA, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC |
| Supplier | Shanghai Rui Tai Photoelectric Technology Co., Ltd. |
Technical data
| Optional I: | UV fused silicafrom CORNING, OHARA, LEONI, AGC,HELLMA, NIKON,VITRON,ETC |
|---|---|
| Optional II: | Equivalent UV fused silicaMade in China, C-laser own brands |
| Lens Shape | Optical Wedge Window | Surface AccuracyIrregularity | – |
| Lens Material | UV GradeFused Silica | Thermal Limit | – |
| Coating | Hardrefractory coating | Chamfers | 10Q20: 0.25-0.76 mm face width20Q20: 0.38-1.14 mm face width |
| Coating Type | – | Chamfers Angle/Tolerance | 45° ±15° |
| Thickness Tolerance | ±38 mm | Wedge | 30 ±15 arc min |
| Surface Quality | 15-5cratch-dig | Clear Aperture | Central 80% of diameter |
What to specify when you request a quote
- Material — listed as “Optical Glass”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “15-5 Scratch-Dig or Custom Manufacturing”; quote surface figure (λ) and scratch-dig.
- Centring and edges — listed as “30 (+-)15 Arc Min”; state centration and edge chamfer.
- Coating — listed as “Hard Refractory Coating or Uncoating”; list the band and reflectance or transmission target.
