The manufacturer offers a glass microfluidic device with the listed channel design, substrate, lid, and fluidic interfaces. Fluidic: 1154. Material chip body: mcs-glass 02. Material chip lid: glass lid (210 µm). Interface type: through-hole. Channel depth: 50 µm.
Overview
Glass Meander Chip – Varying channel shapes – Fuidic 1154 is a microfluidic channel chip made from Glass. Typical applications: Nanoparticle production. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Application | Nanoparticle production |
| Product Family | Microfluidic glass chips |
| Product Reference | 10001528 |
| Design element | Channel |
| Fluidic | 1154 |
| Material chip body | mcs-glass 02 |
| Material chip lid | glass lid (210 µm) |
| Color | Transparent |
| Interface type | through-hole |
| Surface treatment | Not treated |
| Membrane | no membrane |
| Pieces per unit | 1 |
| Usage statement | For R&D use only |
| Channel depth | 50 µm |
| Supplier | microfluidic ChipShop GmbH |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass or quartz grade.
- Outline and thickness — give outline, thickness and tolerances.
- Holes, slots and features — dimension every hole and its position tolerance on the drawing.
- Edges — state edge finish and chamfer.
- Surface — listed as “Not treated”; state polish and flatness where they matter.
