Model: 8615588110989.
Overview
High-Performance Glass Drilling Kit for Professionals and Diyers is a drilled / perforated glass plate. Listed geometry: thickness 3-25mm. Listed for 1. Sink hole in the glass countertop of the cabinet, stove hole and pipe hole applications. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Thickness | 3-25mm |
|---|---|
| Application | 1. Sink hole in the glass countertop of the cabinet, stove hole, pipe hole |
| Model NO. | 8615588110989 |
| Maximum Cutting Thickness | 25 mm |
| Power Supply | 380V, 50Hz, 3phase |
| Safety Features | Emergency Stop Button, Overload Protection, Safety Sensor |
| Product | Small CNC Water Jet Cutting Machine |
| Fuction | Drilling, Cutting, Milling |
| Models | Different Models as Per Customer Size |
| Drawing | Dxf Files |
| Control System | CNC, Servo |
| Spindel Number | 2 |
| Power | 7.3kw |
| Weight | 1800 |
| Drill Bits | 8PCS |
| Cutting Method | Diamond Wheel Cutting, Laser Cutting, Oil Cutter Cutting |
| LB LUBAN LATHE | CNC GLASS MILLING MACHINE AND GLASS DRILLING MACHINE |
| Machine Introduce | This machine is a glass processing equipment newly developed by ZNXU MACHINE that integrates |
| Feature | 1. Self-developed 8-axis control system, perfect and smooth control of glass drilling and glass milling functions; |
| Function | With integrative function drilling cutting milling |
| Supplier | Linyi All-Need Machinery Co., Ltd. |
Technical data
| Model | Machi. Measurement | Max size of glass |
| ZXLB-ZX1200 | 4000*2200*2200mm | 1200*2200mm |
| ZXLB-ZX1500 | 6600*2600*2200mm | 1500*2500mm |
| ZXLB-ZX2000 | 6600*3100*2200mm | 2000*2500mm |
What to specify when you request a quote
- Material — name the glass or quartz grade.
- Outline and thickness — listed as “3-25mm”; give outline, thickness and tolerances.
- Holes, slots and features — listed as “8PCS”; dimension every hole and its position tolerance on the drawing.
- Edges — state edge finish and chamfer.
- Surface — state polish and flatness where they matter.
