Model: KLDJ200Q.
Overview
Industrial Endless CNC Diamond Wire Saw for K9 Corning Optical Glass Cuttin: a shaped glass part. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Model NO. | KLDJ200Q |
|---|---|
| Condition | New |
| Automation | Automatic |
| Suitable for | Quartz Cut ,Ceramic Cut,Optical Glass Cut,Silicon |
| Supplier | Changzhou Kuaile Science and Technology Co., Ltd. |
Technical data
| KLDJ200Q Cutting Machine | ||
| Equipment parameters | ||
| 1 | Workbench size | Φ1700 mm |
| 2 | Linear axis travel | Y1180×Z600 mm |
| 3 | Maximum product size | Φ2000×600 mm |
| 4 | Workbench load-bearing capacity | 5000Kg |
| 5 | Maximum speed of workbench | 10RPM |
| 6 | Maximum linear velocity | 2700 m/min |
| 7 | Processing efficiency | 0.1~1000 mm/min |
| 8 | Diameter of diamond sand loop | Φ0.35~0.8 mm |
| 9 | positioning accuracy | ±0.02 mm |
| 10 | Processing accuracy | ≤0.25mm |
| 11 | Processing surface roughness | Ra ≤ 1.25 |
| 12 | Diamond thread length | 7700 mm |
| 13 | Leading wheel diameter | Φ350 mm |
| 14 | Secondary guide wheel diameter | Φ260 mm(3PCS) |
| 15 | Maximum thrust of cylinder cylinder cylinder cylinder cylinder cylinder cylinder cylinder cylinder cylinder | 377 N |
| 16 | Touch screen size | 7 ″ |
| 17 | Equipment power | 7.5Kw |
| 18 | Gas source pressure | 0.6~0.8 MPa |
| 19 | working voltage | 220V 50Hz ±10% |
| 20 | ambient temperature | 10ºC~30ºC |
| 21 | Equipment weight | 3800 Kg |
| 22 | Equipment body size | 2750×3950×2100 mm |
What to specify when you request a quote
- Material — name the glass or quartz grade.
- Outline and thickness — give outline, thickness and tolerances.
- Holes, slots and features — dimension every hole and its position tolerance on the drawing.
- Edges — state edge finish and chamfer.
- Surface — state polish and flatness where they matter.
Engineering guides for this part
For material grades and coating options, see Fused Silica Wafer Production: A Step-by-Step Manufacturing Guide. How parts like this are machined and finished is covered in Custom Special-Shaped Glass Machining: Boosting B2B Output & Quality. For an application example, read How to Choose Custom Washing Machine Control Panel Glass: A 2026 Buyer's Guide. Before sending a drawing, check Design Guide for Holes, Slots, and Edges in Custom Glass Parts. A related standard product is LED Groove Cover Glass.
FAQ
What should I include in a quote request? expand_more
Include material, outline and thickness, holes, slots and features, edges and surface, plus quantity and a drawing if the part is custom.
