Product type: Insulated. Application: Furniture, Door, Building, Window. Model: dd2.
Overview
Insulated Tempered Low E / ITO Anti-Condensation Printed Display Case Glass Cooler Show Cabinet Freezer Glass Showcase Glass is an ITO-coated glass. Listed geometry: thickness 3mm, flat shape. Typical applications: Furniture, Door, Building and Window. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Type | Insulated |
|---|---|
| Shape | Flat |
| Usage | Furniture, Door, Building, Window |
| Model NO. | dd2 |
| Structure | Hollow |
| Glass Thickness | 3mm |
| Air Cavity Depth | 6mm |
| Moh's Hardness | 7 |
| Energy Transfer | Radiation |
| Deep Processing Depth | Hollow Glass |
| Color | Blue |
| Capability | 1000 Pieces Per Day |
| AS/NZS 2208 | 1996(AU), BS6206(UK), EN12150(EU) |
| Applications | Ideal for freezers, wine cabinets, and display cases. |
| Safety performance | tempered glass will appear hurtless obtuse angles when breakage. |
| Strength performance | Four times more than ordinary glass. |
| Heat stability performance | Three times more than ordinary glass, could bear the temperature change about 200°C. |
| CE—-EN 12150-2 | 2004 European standard. |
| Supplier | Suzhou Yilin Glass Manufacturing Co., Ltd. |
Technical data
| Thickness | 12-100mm |
|---|---|
| Layers | 2 and more |
| Composition | 3+6A+3,5+6A+5, 6+9A+6, 6+12A+6, 6+16A+6,3.2+6A+3.2+6A+3.2 4+6A+4+6A+6 etc. low E or ITO coated |
| Glass Color | clear,ulra clear. |
| Inspection | AS/NZS 2208:1996(AU), BS6206(UK), EN12150(EU) |
| Equipment | Korean insulating line |
| Application | widely used in curtain wall, door, window, icebox |
What to specify when you request a quote
- Sheet resistance — state the target sheet resistance and its tolerance.
- Transmittance — give the minimum visible transmission at the resistance you need.
- Substrate and thickness — listed as “3mm”; name the base glass (soda-lime, borosilicate, alkali-free, quartz) and thickness.
- Size and cutting — give the cut size and whether edges are seamed.
- Pattern or electrodes — send a drawing for any etched pattern, bus bar or electrode.
