Product type: Ball Lens. Application: Optical.
Overview
Manufactory Customized Optical Glass and Sapphire Dome Lens in China is an optical lens made from Optical Glass. Listed geometry: ball lens shape. Optical / electrical data: transmittance >95%. Listed for Optical applications. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass |
|---|---|
| Type | Ball Lens |
| Shape | Ball Lens |
| Transmittance | >95% |
| Usage | Optical |
| Lenses Color | Clear |
| Supplier | Shenyang Ebetter Optics Co., Ltd. |
Technical data
| Diameter Tolerance | +0.0/-0.2mm |
|---|---|
| Diameter | 1-200mm |
| Thickness Tolerance | ±0.1mm |
| Thickness | 1-4mm |
| Surface Quality | 60/40 |
| Material | BK7/Sapphier |
| Height | 1-25mm |
| Coating | AR coating or Custom |
What to specify when you request a quote
- Material — listed as “Optical Glass”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — list the band and reflectance or transmission target.
