Model: CB01-2222.
Overview
Microscope Cover Glass Slide High-Quality Autoglas Cover for Lab Use: a microscope slide / cover slip made from Glass. Listed geometry: thickness 0.1mm, square shape. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Shape | Square |
| Thickness | 0.1mm |
| Model NO. | CB01-2222 |
| Pack | 50PCS/Box |
| Glass | Borosilicate 3.3 |
| Quantity | 100PCS/Box |
| Supplier | Nantong Mevid Life Scientific Co., Ltd. |
Technical data
| Specification (mm) | Thickness #1.0 0.13mm-0.16mm | Thickness #1.5 0.16mm-0.19mm | Thickness #2.0 0.19mm-0.22mm | Packaging |
| 18×18 | CB21-1818 | CB22-1818 | CB23-1818 | 100 pcs/box, 1000 pcs /middle box 50000 pcs/carton |
| 20×20 | CB21-2020 | CB22-2020 | CB23-2020 | 100 pcs/box, 1000 pcs /middle box 50000 pcs/carton |
| 22×22 | CB21-2222 | CB22-2222 | CB23-2222 | 100 pcs/box, 1000 pcs /middle box 50000 pcs/carton |
| 24×24 | CB21-2424 | CB22-2424 | CB23-2424 | 100 pcs/box, 1000 pcs /middle box 50000 pcs/carton |
| 22×32 | CB21-2232 | CB22-2232 | CB23-2232 | 100 pcs/box, 1000 pcs /middle box 50000 pcs/carton |
| 24×32 | CB21-2432 | CB22-2432 | CB23-2432 | 100 pcs/box, 1000 pcs /middle box 50000 pcs/carton |
| 22×40 | CB21-2240 | CB22-2240 | CB23-2240 | 100 pcs/box, 1000 pcs /middle box 40000 pcs/carton |
| 24×40 | CB21-2440 | CB22-2440 | CB23-2440 | 100 pcs/box, 1000 pcs /middle box 40000 pcs/carton |
| 22×50 | CB21-2250 | CB22-2250 | CB23-2250 | 100 pcs/box, 1000 pcs /middle box 30000 pcs/carton |
| 24×50 | CB21-2450 | CEB22-2450 | CB23-2450 | 100 pcs/box, 1000 pcs /middle box 30000 pcs/carton |
| 24×55 | CB21-2455 | CB22-2455 | CB23-2455 | 100 pcs/box, 1000 pcs /middle box 30000 pcs/carton |
| 22×60 | CB21-2260 | CB22-2260 | CB23-2260 | 100 pcs/box, 1000 pcs /middle box 30000 pcs/carton |
| 24×60 | CB21-2460 | CB22-2460 | CB23-2460 | 100 pcs/box, 1000 pcs /middle box 30000 pcs/carton |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass (soda-lime, borosilicate, quartz) because it fixes UV transmission and chemical resistance.
- Dimensions — listed as “0.1mm”; give dimensions and tolerances.
- Surface and edges — state edge finish and any frosted or coated areas.
- Cleanliness and packing — listed as “50PCS/Box”; state cleanliness level and packing for lab use.
