Application: Microscope. Model: dia10mm 12mm 18mm all sizes.
Overview
The Microscope Round Cover Glass Slip with CE Certification Miscroscope is supplied as a microscope slide / cover slip made from Glass. Listed geometry: thickness 1#,1.5#,2#, round shape. Typical applications: Microscope. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Shape | Round |
| Thickness | 1#,1.5#,2# |
| Application | Microscope |
| Usage | Lab and Medical Consumables |
| Quantity | Single |
| Model NO. | dia10mm 12mm 18mm all sizes |
| Color | Transparent/Clear |
| Introduction | The TODOSCAN microscope cover glass is made of super good quality glass. |
| Service Advantages | 1. Professional lab consumables supplier |
| Supplier | SHANGHAI ALLCAN MEDICAL CO., LTD. |
Technical data
| Specificatipn | thickness #1 0.13-0.17m | thickness #1.5 0.13-0.17m | thickness #2 0.19-0.23m | Inner Package |
| Ø8mm | L12108RH1 | L12208RH1 | L12308RH1 | Hinged-lid plastic box,individual aluminum bag,10individual aluminum bag/middle box,20 middle box/carton |
| Ø10mm | L12110RH1 | L12210RH1 | L12310RH1 | |
| Ø11mm | L12111RH1 | L12211RH1 | L12311RH1 | |
| Ø12mm | L12112RH1 | L12212RH1 | L12312RH1 | |
| Ø13mm | L12113RH1 | L12213RH1 | L12313RH1 | |
| Ø14mm | L12114RH1 | L12214RH1 | L12314RH1 | |
| Ø15mm | L12115RH1 | L12215RH1 | L12315RH1 | |
| Ø16mm | L12116RH1 | L12216RH1 | L12316RH1 | |
| Ø18mm | L12118RH1 | L12218RH1 | L12318RH1 | |
| Ø20mm | L12120RH1 | L12220RH1 | L12320RH1 | |
| Ø22mm | L12122RH1 | L12222RH1 | L12322RH1 | |
| Ø24mm | L12124RH1 | L12224RH1 | L12324RH1 | |
| Ø25mm | L12125RH1 | L12225RH1 | L12325RH1 |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass (soda-lime, borosilicate, quartz) because it fixes UV transmission and chemical resistance.
- Dimensions — listed as “1#,1.5#,2#”; give dimensions and tolerances.
- Surface and edges — state edge finish and any frosted or coated areas.
- Cleanliness and packing — state cleanliness level and packing for lab use.
