Model: CH23-2026.
Overview
Microscope Slide Pre-Cleaned Hemaglas Cover Glass for Lab Use: a microscope slide / cover slip made from Glass. Listed geometry: round shape. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Shape | Round |
| Model NO. | CH23-2026 |
| Supplier | Nantong Mevid Life Scientific Co., Ltd. |
Technical data
| Specification (mm) | Thickness #1.0 0.13mm-0.16mm | Thickness #1.5 0.16mm-0.19mm | Thickness #2.0 0.19mm-0.22mm | Packaging |
| Φ8 | CC21-0008 | CC22-0008 | CC23-0008 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ10 | CC21-0010 | CC22-0010 | CC23-0010 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ11 | CC21-0011 | CC22-0011 | CC23-0011 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ12 | CC21-0012 | CC22-0012 | CC23-0012 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ13 | CC21-0013 | CC22-0013 | CC23-0013 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ14 | CC21-0014 | CC22-0014 | CC23-0014 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ15 | CC21-0015 | CC22-0015 | CC23-0015 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ16 | CC21-0016 | CC22-0016 | CC23-0016 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ18 | CC21-0018 | CC22-0018 | CC23-0018 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ20 | CC21-0020 | CC22-0020 | CC23-0020 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ22 | CC21-0022 | CC22-0022 | CC23-0022 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ24 | CC21-0024 | CC22-0024 | CC23-0024 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
| Φ25 | CC21-0025 | CC22-0025 | CC23-0025 | 100 pcs/box, 1000 pcs/middle box 50000 pcs/carton |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass (soda-lime, borosilicate, quartz) because it fixes UV transmission and chemical resistance.
- Dimensions — give dimensions and tolerances.
- Surface and edges — state edge finish and any frosted or coated areas.
- Cleanliness and packing — state cleanliness level and packing for lab use.
