Product type: Flat Lens. Application: Optical. Model: FW-Glass.
Overview
The Optical Glass Double-Convex Aspheric Lens is supplied as an optical lens made from Optical Glass. Listed geometry: size Customized, thickness Customized, single-lens shape. Optical / electrical data: transmittance >95%. Typical applications: Optical. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass |
|---|---|
| Type | Flat Lens |
| Shape | Single-lens |
| Size | Customized |
| Thickness | Customized |
| Transmittance | >95% |
| Usage | Optical |
| Model NO. | FW-Glass |
| Lenses Color | Clear |
| Growth Method | Ky |
| Supplier | Jiaozuo Commercial Finewin Co., Ltd. |
Technical data
| Material | N-bk7,H-K9L,Fused Silica,N-SF10,Silicon,CaF2,Sapphire etc. | ||
| Length | 2~300mm | Centration | <3 arc min |
| Height | 2~300mm | Clear Aperture | >90% |
| Radius | >1.5mm | Flatness(per 25mm at 632.8nm) | <1.5Lambda(General)<1/4Lambda(High Precision) |
| Center Thickness | >0.5mm | Irregularity of Fringes | 0.2-0.5 Lambda |
| Focal Length | 3~3000mm | Surface Quality(S/D) | 60/40,40/20 or better |
| Size Tolerance(mm) | +/-0.1mm,+/-0.05mm | Chamfer | <0.25mmx45 degree |
| Center Thichness Tolerance(mm) | +/-0.1mm,+/-0.05mm | Coating | Uncoated,AR,BBAR,Reflective |
| Focal length Tolerance(mm) | ±1% | Design Wavelength | 632.8nm |
What to specify when you request a quote
- Material — listed as “Optical Glass”; name the glass or crystal.
- Geometry — listed as “Customized”; give diameter, focal length or radii, angles and tolerances.
- Surface figure — quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — list the band and reflectance or transmission target.
