Product type: Rectangular Prism. Application: Beam Dispersion, Beam Split, Laser, Astronomy, Imaging, Detection, etc. Model: OP-0121.
Overview
Optical Glass Square Fused Silica Rectangle Cuboid Prisms Light Guide Rod Beauty Stage Light Four Prism Light Guide Prism is an optical prism in Glass (Znse Prisms substrate). Listed geometry: pentagonal prism shape. Supplied uncoated; surface quality 40-20 Scratch-Dig or Custom Manufacturing; flatness Lambda/10 at 632.8 Nm Over The Clear Aperture. It is used in Medical Instrument. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Substrate | Znse Prisms |
| Type | Rectangular Prism |
| Shape | Pentagonal Prism |
| Surface Quality | 40-20 Scratch-Dig or Custom Manufacturing |
| Application | Medical Instrument |
| Usage | Beam Dispersion, Beam Split, Laser, Astronomy, Imaging, Detection, etc |
| Model NO. | OP-0121 |
| Surface Flatness | Lambda/10 at 632.8 Nm Over The Clear Aperture |
| Coating Type | Uncoated |
| Supplier | C-Laser (Taicang) Material Technology Co., Ltd. |
Technical data
| Material | Zinc selenide(ZnSe) |
|---|---|
| Dimension tolerance | +0/-0.1mm |
| Angle Tolerance | 3″~3′ or custom |
| Surface quality (scratch & dig) | 60-40, 40-20, or better |
| Size | cutom |
| Color | Transparent |
| Coating | AR coating or cutom |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “40-20 Scratch-Dig or Custom Manufacturing”; quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “Uncoated”; list the band and reflectance or transmission target.
