Product type: Convex-Concave. Application: Architecture. Model: OP-RF-67-45.
Overview
The Opulent LED 3030 5050 7070 SMD COB Narrow Beam Glass LED Chip Lenses Reflectors is supplied as an optical mirror made from Borosilicate. It is used in Architecture. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Type | Convex-Concave |
|---|---|
| Application | Architecture |
| Color | Transparent |
| Model NO. | OP-RF-67-45 |
| Glass Type | Borosilicate |
| Glass | Brosilicate Glass |
| Beam Angle | 45 Beam Angle |
| Supplier | Wuxi Opulent Led Lighting Technology Co., Ltd |
What to specify when you request a quote
- Material — name the glass or crystal.
- Geometry — listed as “45 Beam Angle”; give diameter, focal length or radii, angles and tolerances.
- Surface figure — quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — list the band and reflectance or transmission target.
