Product type: Achromatic Lenses. Application: Lighting, Medical, Optical, Photography, Laser. Model: RAY-LH241#.
Overview
The Premium Mgf2 Coated Optical Lens for Superior Clarity and Precision is supplied as an optical lens made from Optical Glass. Listed geometry: single-lens shape. Optical / electrical data: wavelength 587.6 or custom, transmittance >95%. Coating: Mgf2 Coated; surface quality 40-20 or custom. Typical applications: Lighting, Medical, Optical, Photography and Laser. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass |
|---|---|
| Type | Achromatic Lenses |
| Shape | Single-lens |
| Transmittance | >95% |
| Coating | Mgf2 Coated |
| Surface Quality | 40-20 or custom |
| Usage | Lighting, Medical, Optical, Photography, Laser |
| Model NO. | RAY-LH241# |
| Lenses Color | Clear |
| Products Name | MgF2 Coated Achromatic Lenses |
| Alias | MgF2 coating achromatic Lenses, achromatic lens with MgF2 coating, 1.5λ achromatic lens, MgF2 achromatic Lenses |
| Main Tech Specification | Universal Optical Tech Data |
| Optical Lens Type | Achromatic Lens |
| Focal Length Tolerance (%) | ± |
| Focal Length Specification Wavelength (nm) | 587.6 or custom |
| Coating Specification | Ravg |
| Power (P-V) @ 632.8nm | 1.5λor custom |
| Bevel | Protective bevel as needed |
| Wavelength Range (nm) | 400 – 700 or custom |
| Supplier | Shanghai Rui Tai Photoelectric Technology Co., Ltd. |
Technical data
| Universal Optical Tech Data | |
|---|---|
| Optical Lens Type: | Achromatic Lens |
| Focal Length Tolerance (%): | ±2 or custom |
| Focal Length Specification Wavelength (nm): | 587.6 or custom |
| Surface Quality: | 40-20 or custom |
| Coating: | VIS 0°;VIS-NIR;MgF2 Coated Achromatsor custom |
| Coating Specification: | Ravg ≤1.75% at 400 – 700nmor custom |
| Bevel: | Protective bevel as needed |
| Wavelength Range (nm): | 400 – 700 or custom |
| Size/Substrate/Coating Tech Data | |
| Dia. | 1-75mm or custom |
| EFL | 1.5-400mm or custom |
| BFL | 0.92-392.10 or custom |
| Substrate | N-PSK53A/N-LASF9N-BK7/N-SF5N-LAK22/N-SF6N-BAF10/N-SF10N-SSK8/N-SF56N-BASF64/N-SF66S-BAH11/N-SF10ETC. |
| Coating | MgF2or custom |
What to specify when you request a quote
- Material — listed as “Optical Glass”; name the glass or crystal.
- Geometry — listed as “±”; give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “40-20 or custom”; quote surface figure (λ) and scratch-dig.
- Centring and edges — listed as “Protective bevel as needed”; state centration and edge chamfer.
- Coating — listed as “Mgf2 Coated”; list the band and reflectance or transmission target.
