Product type: Tube. Application: Optical, Photography. Model: X-P23V3M13901.
Overview
The Round Quartz Glass Substrate for Optical Components Measurement Devices Laboratory Systems Glass Wafer is supplied as a fused silica / quartz wafer made from Optical Glass. Listed geometry: thickness 0.5mm, single-lens shape. Optical / electrical data: transmittance >95%. Coating: Customized. It is used in Optical and Photography. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass |
|---|---|
| Type | Tube |
| Shape | Single-lens |
| Thickness | 0.5mm |
| Transmittance | >95% |
| Coating | Customized |
| Usage | Optical, Photography |
| Model NO. | X-P23V3M13901 |
| Lenses Color | Clear |
| Materials | Jgs2 |
| Width | 16mm |
| Length | 80mm |
| Supplier | VY Optoelectronics Co., Ltd. |
What to specify when you request a quote
- Diameter and flat / notch — state diameter, flat or notch and their tolerances.
- Thickness and TTV — listed as “0.5mm”; give thickness, its tolerance and total thickness variation.
- Polish and roughness — specify single- or double-side polish and roughness.
- Flatness, bow and warp — quote flatness, bow and warp limits.
- Material grade — listed as “Optical Glass”; name the grade (JGS1/JGS2, Borofloat 33, alkali-free, sapphire orientation).
