Product type: Plano-Convex Lenses. Application: Lighting, Medical, Optical, Photography, Laser, Astronomy, Imaging, Detection, etc. Model: RAY-XS083#.
Overview
Sapphire Lens/Optical Sapphire Lens/Sapphire Infrared Lens: an optical lens in Optical Glass (Calcium Fluoride substrate). Listed geometry: single-lens shape. Optical / electrical data: wavelength Uncoated, transmittance >95%. Supplied uncoated; surface quality 40-20 Scratch-Dig or Custom. Typical applications: Lighting, Medical, Optical, Photography and Laser. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass |
|---|---|
| Substrate | Calcium Fluoride |
| Type | Plano-Convex Lenses |
| Shape | Single-lens |
| Transmittance | >95% |
| Coating | Uncoated |
| Surface Quality | 40-20 Scratch-Dig or Custom |
| Usage | Lighting, Medical, Optical, Photography, Laser, Astronomy, Imaging, Detection, etc |
| Model NO. | RAY-XS083# |
| Lenses Color | Clear |
| Ar Coating Wavelength | Uncoated |
| Coating Type | Uncoated |
| Surface Accuracy Irregularity | Lambda/4 at 633 Nm |
| Lens Substrate | Sapphire |
| Optional I | Sapphire |
| Optional II | Equivalent Sapphire |
| Main Applying | 1). High infrared transmission. |
| Main Optical Tech Specification | Lens Shape |
| Main Cooperation Materials Manufacturers | CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC |
| Supplier | Shanghai Rui Tai Photoelectric Technology Co., Ltd. |
Technical data
| Optional I: | Sapphirefrom CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,ETC |
|---|---|
| Optional II: | Equivalent SapphireMade in China, C-laser own brands |
| Lens Shape | Plano-Convex | Surface AccuracyIrregularity | – |
| Lens Material | Sapphire | Surface Accuracy, Power | – |
| Antireflection Coating | Uncoated | Chamfers | – |
| Coating Type | – | Chamfers Angle/Tolerance | – |
| Coating Code | – | Focal LengthTolerance | – |
| Damage Threshold | – | Centration | ≤3 arc min |
| Surface Quality | 60-40 scratch-dig | Clear Aperture | ≥central 90% ofdiameter |
| Surface Flatness | – | OEM/ODM | Accepted |
What to specify when you request a quote
- Material — listed as “Optical Glass”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “40-20 Scratch-Dig or Custom”; quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “Uncoated”; list the band and reflectance or transmission target.
