Product type: Optical Windows. Application: Lighting, Medical, Optical, Photography, Laser, Astronomy, Imaging, Detection, etc. Model: RAY-OW040#.
Overview
The Sapphire Parallel Window/Sapphire Optical Windows/Sapphire Optical Lens is supplied as an optical lens in Optical Glass (Sapphire substrate). Listed geometry: thickness 2-3.2mm or Custom Manufacturing, single-lens shape. Optical / electrical data: wavelength 150-5000nm, transmittance >95%. Supplied uncoated; surface quality 40-20 Scratch-Dig or Custom Manufacturing; flatness 2lambda at 633nm or Custom Manufacturing. It is used in Lighting, Medical, Optical, Photography and Laser. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass |
|---|---|
| Substrate | Sapphire |
| Type | Optical Windows |
| Shape | Single-lens |
| Thickness | 2-3.2mm or Custom Manufacturing |
| Wavelength Range | 150-5000nm |
| Transmittance | >95% |
| Coating | Uncoating |
| Surface Quality | 40-20 Scratch-Dig or Custom Manufacturing |
| Usage | Lighting, Medical, Optical, Photography, Laser, Astronomy, Imaging, Detection, etc |
| Model NO. | RAY-OW040# |
| Lenses Color | Clear |
| Surface Flatness | 2lambda at 633nm or Custom Manufacturing |
| Products Name | Sapphire Parallel Window |
| Lens Substrates | Sapphire |
| Optional I | Sapphire Substrates |
| Optional II | Equivalent Sapphire Substrates |
| Uncoating | Wide transmission range |
| Applying Fields I | Harsh optical applying conditions. |
| Applying Fields II | Other |
| Main Optical Tech Specification | Lens Shape |
| SAW | 0.008 for visible light orthogonal to optical axis |
| SW8 | central 80% of diameter |
| Popular Physical Size Specification | Basic Data |
| Main Cooperation Materials Manufacturers | CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC |
| Supplier | Shanghai Rui Tai Photoelectric Technology Co., Ltd. |
Technical data
| Optional I: | Sapphire Substratesfrom CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,ETC |
|---|---|
| Optional II: | Equivalent Sapphire SubstratesMade in China, C-laser own brands |
| Applying Fields I: | Harsh optical applying conditions.Make an observation window to observe the interior of vacuum cavity or cavity containing high temperature plasma |
|---|---|
| Applying Fields II: | Other |
| ***** |
| Lens Shape | Optical Parallel Window | Surface AccuracyIrregularity | – |
| Lens Material | Sapphire | Surface Accuracy, Power | – |
| Antireflection Coating | Uncoating | Thermal Limit | 22 W m-1 K-1 |
| Coating Type | – | Thermal Expansion Coefficient | 8.4 x 10-6 K-1 |
| Coating Code | – | Edge Finish | Ground and beveled |
| Wavelength Range | 150-5000nm | Birefringence | SAW: 0.008 for visible light orthogonal to optical axis |
| Surface Quality | 40-20 scratch-dig80-50 scratch-dig | Clear Aperture | SW8: central 80% of diameterSAW: central 90% of diameter |
| Surface Flatness | 2λ at 633 nmλ/4 at 633 nm | OEM/ODM | Accepted |
What to specify when you request a quote
- Material — listed as “Optical Glass”; name the glass or crystal.
- Geometry — listed as “Basic Data”; give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “40-20 Scratch-Dig or Custom Manufacturing”; quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “Uncoating”; list the band and reflectance or transmission target.
