Product type: Lens. Application: Lighting, Medical, Optical. Model: FSOL.
Overview
Sturdy Optical Dome Lens with Reinforced Impact Resistance and Weatherproof Design for Outdoor and Harsh Environment Use: an optical lens made from Optical Glass. Listed geometry: ball, hemisphere shape. Optical / electrical data: transmittance >95%. Coating: HC; surface quality 20/10 or Better. Listed for Lighting, Medical and Optical applications. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Optical Glass |
|---|---|
| Type | Lens |
| Shape | Ball, Hemisphere |
| Transmittance | >95% |
| Coating | HC |
| Surface Quality | 20/10 or Better |
| Clear Aperture | >90% |
| Usage | Lighting, Medical, Optical |
| Model NO. | FSOL |
| Lenses Color | Clear |
| Model No | Fsol |
| Principle | Ar Coating |
| Supplier | Tianjin Fushi Optical Technology Co., Ltd. |
Technical data
| PRODUCT NAME | Dome Lens |
|---|---|
| PRODUCT SIZE | 0.1 – 600mm |
| EFFECTIVE FOCAL LENGTH | 250mm |
| DIAMETER TOLERANCE | +0.0/-0.1mm |
| TRANSMITTANCE | 95% |
| TYPE | Optical Lens |
What to specify when you request a quote
- Material — listed as “Optical Glass”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “20/10 or Better”; quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “HC”; list the band and reflectance or transmission target.
Engineering guides for this part
For material grades and coating options, see Fused Silica Wafer Production: A Step-by-Step Manufacturing Guide. How parts like this are machined and finished is covered in Optical Glass Polishing for High Clarity Surfaces. For an application example, read Boost Yield with Fused Silica Viewports for Vacuum and Optical Systems. Before sending a drawing, check Fused Silica Refractive Index: Key to Optical Design Improvement. A related standard product is Fused Silica Glass Wafers (2–12", JGS1/JGS2).
