The Synthetic Blue Sapphire Crystal Wafers is supplied as a sapphire / specialty wafer made from Optical Glass. Listed geometry: diameter 1mm-500mm, cylindrical shaped lens shape. Optical / electrical data: transmittance >95%. Coating: UV; surface quality 40/20;60/40; flatness 1/4 Lambda. Listed for Optical applications. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
Material
Optical Glass
Type
Concave Lens
Shape
Cylindrical Shaped Lens
Diameter
1mm-500mm
Transmittance
>95%
Coating
UV
Surface Quality
40/20;60/40
Usage
Optical
Model NO.
FW-sapphire
Lenses Color
Clear
Coat
Anti-Reflective (Ar) Coatings
Clear Aperture: >90% of Diameter
>90% of Diameter
Surface Flatness
1/4 Lambda
Clear Aperture
>90% of Diameter: >90% of Diameter
Supplier
Jiaozuo Commercial Finewin Co., Ltd.
Technical data
Refractive index (nd)
1.768
Coefficient of dispersion (Vd)
72.2
Density (g/cm3)
3.97
TCE(μm/mºC)
5.3
Soften Temperature(ºC)
2000
Knoop hardness(kg/mm2)
2200
Diameter
0.2-300mm +/-0.1mm or +/-0.02mm or customization
Thickness
0.10-100mm± 0.1mm or +/-0.02mm
Surface quality (scratch & dig)
60/40, 40/20 or better
Surface accuracy
λ/10, λ/2, λ
Clear Aperture
>85%, >90%
Parallelism
+/-3' ,+/-30''
Bevel
0.1~0.3mm×45 degree
coating
AR, BBAR or upon customer request( UV, VIS, IR)
Brand name
FineWin
Material
Optical Glass
Color
Clear or custom color
Application
Lamp shade
Surface
Clean and no bubble
Size
As per your drawing or requirement
Logo
Customized logo is accepted
MOQ
1000pcs
Production Capacity
10000pcs/mont
What to specify when you request a quote
Diameter and flat / notch — listed as “1mm-500mm”; state diameter, flat or notch and their tolerances.
Thickness and TTV — give thickness, its tolerance and total thickness variation.
Polish and roughness — listed as “40/20;60/40”; specify single- or double-side polish and roughness.
Flatness, bow and warp — listed as “1/4 Lambda”; quote flatness, bow and warp limits.
Material grade — listed as “Optical Glass”; name the grade (JGS1/JGS2, Borofloat 33, alkali-free, sapphire orientation).
What is the Synthetic Blue Sapphire Crystal Wafers made of? expand_more
It is listed as Optical Glass. Coating: UV. Other grades can be quoted if your application needs different transmission, thermal or chemical properties.
What sizes and thicknesses are available? expand_more
The listing gives diameter 1mm-500mm. Custom outlines and thicknesses are made to drawing; state the tolerance you need.
What optical or electrical performance does it have? expand_more
Listed values: transmittance >95%. Confirm the values at your operating wavelength, angle and temperature when you request a quote.
Where is this sapphire / specialty wafer used? expand_more
Listed applications: Optical.
What should I include in a quote request? expand_more
Include diameter and flat / notch, thickness and ttv, polish and roughness, flatness, bow and warp and material grade, plus quantity and a drawing if the part is custom.
