Product type: Coating Production Line. Application: Mineral Glass Optical Lens, Polymer Optical Lens. Model: CCAK-OGS.
Overview
The Industrial Vacuum Cczk-Ogs Coater for Optical Glass Resin Lens Telescope Objective Multi-Film Coating is supplied as an optical lens made from Glass/Arcylic. Coating: Vacuum Coating. Listed for Mineral Glass Optical Lens and Polymer Optical Lens applications. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Substrate | Glass/Arcylic |
|---|---|
| Type | Coating Production Line |
| Coating | Vacuum Coating |
| Application | Mineral Glass Optical Lens, Polymer Optical Lens |
| Model NO. | CCAK-OGS |
| Condition | New |
| Machine Type | Optical Vacuum Metallizing Machine |
| Chamber Size | Diameter 600mm – Diameter 1800mm or as Request |
| Coating Color | Blue, Rainbow Color, etc |
| Coating Film | Ar Coating; Beam Splitter;Hr Coating |
| Electron Beam Gun | 6kw, 10kw, 20kw |
| Film Thickness | up to 99 Layers Deposition |
| Voltage | 380 V or as Request |
| After Sales | Free Training & Oversease After Sales Available |
| Supplier | Jiangsu Cicel Vacuum Technology Co., Ltd. |
What to specify when you request a quote
- Material — listed as “Glass/Arcylic”; name the glass or crystal.
- Geometry — listed as “Diameter 600mm – Diameter 1800mm or as Request”; give diameter, focal length or radii, angles and tolerances.
- Surface figure — quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “Vacuum Coating”; list the band and reflectance or transmission target.
