Model: Laser Scanning Mirrors.
Overview
Ireeda Optical Mirror UV Laser Scanning Mirrors YAG Green Light Galvo Mirrors: an optical mirror made from Fused Silica / Silicon / Bk7. Listed geometry: size Customizable (10x12mm, 14x16mm, 20x25mm, etc.), rectangular / octagonal / custom shape. Optical / electrical data: wavelength 266nm / 355nm (UV), 532nm (Green), 1064nm (YAG/Fiber), 10.6μm (CO2). Coating: Dielectric / Protected Gold / Silver; surface quality 10-5 (Scratch-Dig). Typical applications: High speed laser scanning, marking, engraving and welding. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Substrate | Fused Silica / Silicon / Bk7 |
|---|---|
| Shape | Rectangular / Octagonal / Custom |
| Size | Customizable (10x12mm, 14x16mm, 20x25mm, etc.) |
| Wavelength Range | 266nm / 355nm (UV), 532nm (Green), 1064nm (YAG/Fiber), 10.6μm (CO2) |
| Wavelength | 355nm / 532nm / 1064nm / 10.6μm |
| Coating | Dielectric / Protected Gold / Silver |
| Surface Quality | 10-5 (Scratch-Dig) |
| Application | High speed laser scanning, marking, engraving, welding |
| Model NO. | Laser Scanning Mirrors |
| Laser Damage Threshold | High (UV/IR Grade) |
| Substrate Material | Fused Silica (UV/Green), Silicon (YAG/IR), BK7 (Visible) |
| UV & Green lasers | UV Fused Silica (high LIDT, low absorption) |
| YAG / Fiber / IR lasers | Silicon (Si) (lightweight, high thermal stability) |
| Standard visible light | BK7 / K9 glass |
| UV | 266nm, 355nm |
| Green | 532nm |
| YAG / Fiber | 1064nm, 1080nm |
| UV/Green | IBS dielectric coating, reflectivity ≥ 99.5% |
| YAG/Fiber/CO2 | Protected gold coating, reflectivity ≥ 98% |
| Standard shapes | rectangle, round, octagonal |
| Common sizes | 10×12mm, 14×16mm, 20×25mm, 25×30mm, 30×40mm |
| Yes, we support full customization | Custom wavelength coating |
| Standard bulk orders | 7–15 working days |
| Custom coated products | 15–20 working days |
| Each mirror is 100% tested | Reflectivity test |
| Supplier | Shaanxi Ireeda Protective Technology Co., Ltd. |
Technical data
| Product Name | UV / Green / YAG Laser Scanning Galvo Mirror |
|---|---|
| Wavelength | 355nm / 532nm / 1064nm / 10600nm |
| Substrate Material | Fused Silica / Silicon / BK7 |
| Coating Type | Dielectric Coating / Protected Gold Coating |
| Surface Quality | 10-5 / 20-10 Scratch-Dig |
| Shape | Round / Rectangular / Octagonal |
| Size | 10×12mm, 14×16mm, 20×25mm, 25×30mm, Custom |
| Thickness | 1–6mm |
| Laser Damage Threshold | High (Laser Grade) |
| Application | Laser Marking, Engraving, Cutting, Welding, Scanning |
What to specify when you request a quote
- Material — listed as “Fused Silica / Silicon / Bk7”; name the glass or crystal.
- Geometry — listed as “Customizable (10x12mm, 14x16mm, 20x25mm, etc.)”; give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “10-5 (Scratch-Dig)”; quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “Dielectric / Protected Gold / Silver”; list the band and reflectance or transmission target.
