Application: Medical, Civil, Labs. Model: FSOM.
Overview
off-Axis Parabolic Mirror Aluminum-Coated in Stock Optical Concave Mirror Factory Direct Sale is an optical mirror made from Glass. Listed geometry: size Customized, paraboloid shape. Coating: Customized; surface quality 40/20 or Better. Listed for Medical, Civil and Labs applications. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Shape | Paraboloid |
| Dimension | Customized |
| Coating | Customized |
| Surface Quality | 40/20 or Better |
| Application | Medical, Civil, Labs |
| Model NO. | FSOM |
| Model No | Fsom-1 |
| Supplier | Tianjin Fushi Optical Technology Co., Ltd. |
Technical data
| Metallic Coating | Protected Gold, Protected Silver, Protected Aluminum |
|---|---|
| Off-Axis Angle | Customized |
| Surface Quality | 20/10 or better |
| Manufacturing Process | Diamond Turned |
| Transmittance | Optical Reflector |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass or crystal.
- Geometry — listed as “Customized”; give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “40/20 or Better”; quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “Customized”; list the band and reflectance or transmission target.
