Application: Medical, Civil, Labs. Model: 12222112.
Overview
Optical /Dental/ Mouth/Front Surface Mirror is an optical mirror made from Glass. Listed geometry: size 700mm*930mm Thickness: 2mm-12mm, ball shape. It is used in Medical, Civil and Labs. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Shape | Ball |
| Size | 700mm*930mm Thickness: 2mm-12mm |
| Application | Medical, Civil, Labs |
| Model NO. | 12222112 |
| Mirror | Dental Mirror |
| Mouth Mirror | Front Surface Mirror |
| Front Surface Mirror | Projection Curtain Wall |
| Optical Mirror | Projector Mirror |
| Photocopy Equipment Mirror | Rear-Projection TV Mirror |
| Applications | projection curtain wall, projector, Rear-projection TV, Photocopy equipment , Dental Instrument / Dental mirror/ mouth mirror and other optical devices. |
| Processing type | Edge grinding, grilling. |
| Supplier | Foshan Xingang Glass Co., Ltd. |
Technical data
| Coating surface | Y=94.22 | L=98.10 | a=-0.70 | b=-1.00 |
| Front surface mirror | Mostly Aluminum coated |
|---|---|
| Thickness | 2mm , 3mm mostly used |
| Payment terms | T/T payment Paypal |
| Advantage | NO double images |
| Samples | Can make samples according to customers' requirements . |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass or crystal.
- Geometry — listed as “700mm*930mm Thickness: 2mm-12mm”; give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “Projection Curtain Wall”; quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — list the band and reflectance or transmission target.
