Product type: Flat Lens. Application: Medical, Optical, Photography, Lasers. Model: yt8988.
Overview
Optical Scanning Galvo Mirror for CO2 Laser: an optical mirror made from Molybdenum. Listed geometry: diameter 20mm, single-lens shape. Optical / electrical data: transmittance R>97%. Coating: Reflection Coating. Typical applications: Medical, Optical, Photography and Lasers. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Molybdenum |
|---|---|
| Type | Flat Lens |
| Shape | Single-lens |
| Transmittance | R>97% |
| Coating | Reflection Coating |
| Usage | Medical, Optical, Photography, Lasers |
| Model NO. | yt8988 |
| Lenses Color | Silver |
| Color | Silver |
| Dia | 20mm |
| Dia Tol. | +0.1/-0.1mm |
| Thick | 3mm |
| C.a. | 90% |
| Scanning mirrors include two pieces for one pair | X-axis mirror |
| Supplier | Changchun Yutai Optics Co., Ltd. |
Technical data
| Scanning mirror | ||||
| Mirror Types | YAG Scanning mirror | CO2 Scanning mirror | ||
| Aperture(mm) | X-axis(Lx Wx H) | Y-axis(Lx Wx H) | X-axis(Lx Wx H) | Y-axis(Lx Wx H) |
| 10 | 18.3*13*2 | 23.2*16*1.5 | 18.3*13*2 | 23.2*16*2 |
| 12 | 21*16.8*2 | 30*19*2 | 21*16*2 | 30*19*2 |
| 16 | 28*20*2 | 37*22*2 | 27*20*2.5 | 37.6*22.5*2.5 |
| 20 | 37*25*2.5 | 47*31*2.5 | 37*25.5*3 | 47*31*3 |
| 25 | 45*30*3 | 60*39*3 | 45*30*3 | 56.39*3 |
| 30 | / | / | 54*35*4 | 62*43*4 |
What to specify when you request a quote
- Material — listed as “Molybdenum”; name the glass or crystal.
- Geometry — give diameter, focal length or radii, angles and tolerances.
- Surface figure — quote surface figure (λ) and scratch-dig.
- Centring and edges — state centration and edge chamfer.
- Coating — listed as “Reflection Coating”; list the band and reflectance or transmission target.
