Application: Medical, Labs. Model: FSOM.
Overview
Versatile Optical Brewster Mirrors Components Rooted in Brewster's Law for a Myriad of Scenarios, From Traditional Optics to Emerging Biomedicine is an optical mirror made from Glass. Listed geometry: flat shape. It is used in Medical and Labs. Dimensions, material grade, coating and finish can be quoted to your drawing; the values above are the listed starting point.
Specifications
| Material | Glass |
|---|---|
| Shape | Flat |
| Application | Medical, Labs |
| Model NO. | FSOM |
| Size Error | +0.0 / -0.1mm |
| Beveling | 0.2mm X 45° |
| Thickness Tolerance | ±0.2 |
| Surface Finish | 40/20 |
| Supplier | Tianjin Fushi Optical Technology Co., Ltd. |
Technical data
| PRODUCT NAME | Reflective Mirror |
|---|---|
| PRODUCT SIZE | 80,90MM |
| SURFACE PERFECTION | 40-20-60-40 |
| DIAMETER TOLERANCE | +0.0/-0.1MM |
| MATERIAL | QUARTZ GLASS |
| TRANSMITTANCE | 95% |
| TYPE | Optical Reflector |
What to specify when you request a quote
- Material — listed as “Glass”; name the glass or crystal.
- Geometry — listed as “+0.0 / -0.1mm”; give diameter, focal length or radii, angles and tolerances.
- Surface figure — listed as “40/20”; quote surface figure (λ) and scratch-dig.
- Centring and edges — listed as “0.2mm X 45°”; state centration and edge chamfer.
- Coating — list the band and reflectance or transmission target.
Engineering guides for this part
For material grades and coating options, see Fused Silica Windows for UV and Laser Optical Systems. How parts like this are machined and finished is covered in Laser Glass Etching for Fine Marking and Surface Features: A B2B Manufacturing Guide. For an application example, read How to Handle and Maintain Precision Glass Components in Laser Systems. Before sending a drawing, check Technical Guide to Glass Thickness and Flatness Requirements. A related standard product is Laser Beam Splitter Glass Sheet.
