6 Inch (150 mm) Quartz Glass Wafers

6 Inch (150 mm) Quartz Glass Wafers: Quartz Glass, CTE 0.59 x 10^-6 /K. No MOQ, prototypes in 5-10 days, DFM review with every RFQ.

6 Inch (150 mm) Quartz Glass Wafers

6 Inch (150 mm) Quartz Glass Wafers: Quartz Glass (CTE 0.59 x 10^-6 /K, 260 nm – 2.5 um); 150 mm format, TTV <3 um. Single-piece prototypes to production volumes, quoted from your drawing.

6 inch (150 mm) quartz glass wafers are supplied as finished substrates: edge-rounded, cleaned and packed in wafer cassettes. The material brings fused from natural quartz crystal and plasma and halogen resistance; the format brings SEMI-compatible handling.

Specifications at a glance

Material Quartz Glass (GE214-equivalent, semiconductor grade)
Thermal expansion (CTE) 0.59 x 10^-6 /K
Service temperature 1,050 C continuous
Transmission range 260 nm – 2.5 um
Density 2.20 g/cm3
Knoop hardness 500 kg/mm2
Refractive index 1.459 @ 587 nm
Stock thickness 0.20 – 60 mm
Maximum blank size 450 mm diameter
Diameter / format 150 mm
Thickness 0.5 – 1.1 mm
TTV <3 um
Flat / notch SEMI notch or flat
RFQ inputs PDF/DXF/STEP drawing, quantity brackets, surface and edge spec

Process window

Beyond this page, Quartz Glass routinely runs through etching, laser cutting, coring, dicing in our shop – most real parts combine two or three of these steps.

Specification advice

Before sending the RFQ, check these against your drawing:

  • Material note: natural-quartz batches vary in metallic ppm, so semiconductor lots need certs per melt.
  • Specify flat or notch orientation relative to your device layout – regrinding orientation later scraps the wafer.
  • Over-specification is the quiet budget killer: a 20/10 scratch-dig face costs roughly three times an 80/50 face, so grade each surface individually.

For the complete framework, see the tolerance design guide and the holes and edges design guide.

Application context

6 inch (150 mm) quartz glass wafers shows up across semiconductor equipment (view ports, wafer carriers, plasma rings, chamber windows); laboratory instruments (cuvettes, sight glasses, stir-cell windows). Background reading on the underlying material science: ScienceDirect: quartz glass.

The fastest route to a quote is geometry: use the 3D builder below, draw a dimensioned 2D drawing from it, or open the site-wide custom glass machining 3D + 2D builder for fully custom parts.

Engineers scoping this work usually also review precision glass grinding, JGS1 quartz glass, custom FTO glass.

Common questions

How fast can prototypes ship?

Machined prototypes ship in 5 – 10 working days. Coated or bonded parts add 1 – 2 weeks depending on queue slots.

What files do you need for a quote?

A dimensioned PDF plus DXF or STEP geometry. If only a sketch exists, our drawing review service formalizes it before quoting.

Do parts ship with inspection data?

Dimensional reports, surface certificates and material certs per melt are available; specify the level on the RFQ.

What tolerances are achievable on Quartz Glass parts?

Ground features hold +/-0.01 mm and lapped thickness reaches +/-0.003 mm. Natural-quartz batches vary in metallic ppm, so semiconductor lots need certs per melt.

What thickness range do you stock for Quartz Glass?

Standard stock spans 0.20 – 60 mm, with blanks up to 450 mm diameter. Other formats are sourced per order.

Specifications on this page were last reviewed by our engineering team in September 2026.

Configure in 3D, draw in 2D

3D Model & 2D Drawing Builder

PRECISION GLASS 3D
3D Precision Glass Configurator Build a visual 3D preview for custom precision glass parts, including wafers, microfluidic chips, coated glass, optical filters, and machined quartz plates. This tool is for visual configuration only. Final dimensions, tolerances, materials, coatings, and manufacturability will be reviewed from your drawing or specification.
3D GLASS PREVIEW Visual Specification

Glass Wafer Builder

Interactive visual preview for custom precision glass configuration.

SP SPEC SUMMARY:
Import Code (One-Click Recall)

Save this code before you leave — it is the only way to recall this exact model. If you lose it, your configuration cannot be restored.

SUBMIT RFQ — ENGINEERING REVIEW Your current 3D configuration and specification summary are attached automatically. Attach a drawing if you have one.
Arithmetic verification image

FREQUENTLY ASKED QUESTIONS
Which fused silica grade should I choose — JGS1, JGS2 or JGS3?

JGS1 offers deep-UV transmission from about 185 nm (best for DUV lithography and UV laser optics). JGS2 transmits well from about 220 nm for standard UV-visible use at lower cost. JGS3 is optimized for visible-to-infrared and high-power laser work. The builder exposes a transmission-band requirement so you can specify the grade by application.

What wafer diameters and thicknesses are supported?

Common diameters are 2, 3, 4 and 6 inch (note 1 inch = 25.0 mm for quartz wafers, so a 4 inch wafer is 100 mm). Typical thicknesses are 200, 500, 700 and 1000 µm, with tighter thickness tolerance and TTV specifiable for polished optical grades.

Can I specify TTV, surface quality and a flat or notch?

Yes. You can set total thickness variation, scratch-dig surface quality (down to 40/20 or 20/10 for optical grade), single- or double-side polish, and a primary flat or notch for orientation.

Need a different product family? Open the full 3D + 2D builder.
