Optical Glass Rectangular Glass Plates – Optical Glass (CTE 7.1 x 10^-6 /K, 350 nm – 2.0 um); Up to 600 x 400 mm, thickness 0.2 – 40 mm. No minimum order; DFM review included with every RFQ.
optical glass rectangular glass plates are ordered for stage plates, machine guards and optical breadboards. The geometry envelope is Up to 600 x 400 mm, thickness 0.2 – 40 mm, held to length/width +/-0.05 mm, in Optical Glass.
Specifications at a glance
| Material | Optical Glass (N-BK7, H-K9L and filter glass sets) |
|---|---|
| Thermal expansion (CTE) | 7.1 x 10^-6 /K |
| Service temperature | 400 C (Tg 557 C) |
| Transmission range | 350 nm – 2.0 um |
| Density | 2.51 g/cm3 |
| Knoop hardness | 610 kg/mm2 |
| Refractive index | 1.5168 @ 587 nm |
| Stock thickness | 0.30 – 50 mm |
| Maximum blank size | 300 mm diameter |
| Geometry | Rectangular Glass Plates |
| Size envelope | Up to 600 x 400 mm, thickness 0.2 – 40 mm |
| Key tolerance | length/width +/-0.05 mm |
| RFQ inputs | PDF/DXF/STEP drawing, quantity brackets, surface and edge spec |
Capabilities and limits
One material, many routes: on Optical Glass we also quote cnc machining, ultrasonic machining, polishing, laser cutting, and multi-step drawings are the norm rather than the exception.
Production route: cnc machining, grinding, edge grinding – selected per geometry and volume. Edge condition: chamfered 0.1 – 0.5 mm as standard.
Getting the drawing right
Three items decide most of the cost and lead time on this work:
- Material note: index-certified blanks must be oriented and serialized through the shop to keep melt traceability.
- Hold the controlling dimension (length/width +/-0.05 mm) and let secondary dimensions carry standard tolerance – it is the single biggest cost lever.
- Over-specification is the quiet budget killer: a 20/10 scratch-dig face costs roughly three times an 80/50 face, so grade each surface individually.
For the complete framework, see the tolerance design guide and the holes and edges design guide.
Where these parts end up
The recurring buyers of optical glass rectangular glass plates: optical sensors (sensor windows, filter caps, lens covers); scientific instruments (reference flats, cells, prism mounts, stage inserts); ccd inspection equipment (CCD cover plates, reference grids, stage glass). Background reading on the underlying material science: RP Photonics: optical glass.
Dimensions still moving? Configure this part live in the 3D + 2D builder below, or open the full custom glass machining 3D + 2D builder to start from a blank canvas.
Useful companion pages: precision glass grinding, CCD screening plates, thickness and flatness guide.
Frequently asked questions
Is there a minimum order for optical glass rectangular glass plates?
No. Single prototypes are accepted, and pricing steps down at 10, 100 and 1,000 pieces.
How fast can prototypes ship?
Machined prototypes ship in 5 – 10 working days. Coated or bonded parts add 1 – 2 weeks depending on queue slots.
What files do you need for a quote?
A dimensioned PDF plus DXF or STEP geometry. If only a sketch exists, our drawing review service formalizes it before quoting.
Do parts ship with inspection data?
Dimensional reports, surface certificates and material certs per melt are available; specify the level on the RFQ.
Specifications on this page were last reviewed by our engineering team in September 2026.
