Quick answer: Custom Special-Shaped Glass covers Any DXF/STEP outline within 600 x 400 mm. Prototypes ship in 5-10 working days.
A drawing for custom special-shaped glass is mostly a conversation about edges and datums. We produce them in fused silica, Borofloat 33, quartz and soda-lime at Any DXF/STEP outline within 600 x 400 mm, with contour +/-0.05 mm as the controlling tolerance, and finish the perimeter per spec.
Specifications at a glance
| Geometry | Special-Shaped Glass |
|---|---|
| Size envelope | Any DXF/STEP outline within 600 x 400 mm |
| Key tolerance | contour +/-0.05 mm |
| RFQ inputs | PDF/DXF/STEP drawing, quantity brackets, surface and edge spec |
Capabilities and limits
Production route: cnc machining, laser cutting, edge grinding – selected per geometry and volume. Edge condition: chamfered 0.1 – 0.5 mm as standard.
Design guidance
The shop-floor rules that matter here:
- Hold the controlling dimension (contour +/-0.05 mm) and let secondary dimensions carry standard tolerance – it is the single biggest cost lever.
- Over-specification is the quiet budget killer: a 20/10 scratch-dig face costs roughly three times an 80/50 face, so grade each surface individually.
The full rules live in our tolerance design guide and holes and edges design guide.
Where these parts end up
custom special-shaped glass shows up across scientific instruments (reference flats, cells, prism mounts, stage inserts); machine vision (camera windows, ring-light diffusers, calibration plates); laboratory instruments (cuvettes, sight glasses, stir-cell windows).
Dimensions still moving? Configure this part live in the 3D + 2D builder below, or open the full custom glass machining 3D + 2D builder to start from a blank canvas.
Useful companion pages: special-shaped glass plates, ultra-thin quartz discs, glass hole micromachining.
Buyer questions, answered
Do parts ship with inspection data?
Dimensional reports, surface certificates and material certs per melt are available; specify the level on the RFQ.
What sizes are available for special-shaped glass?
Any DXF/STEP outline within 600 x 400 mm, held to contour +/-0.05 mm.
Is there a minimum order for custom special-shaped glass?
No. Single prototypes are accepted, and pricing steps down at 10, 100 and 1,000 pieces.
How fast can prototypes ship?
Machined prototypes ship in 5 – 10 working days. Coated or bonded parts add 1 – 2 weeks depending on queue slots.
Specifications on this page were last reviewed by our engineering team in September 2026.
