Soda-Lime Glass Round Glass Discs

Soda-Lime Glass Round Glass Discs: Soda-Lime Glass, CTE 9.0 x 10^-6 /K. No MOQ, prototypes in 5-10 days, DFM review with every RFQ.

Soda-Lime Glass Round Glass Discs

Soda-Lime Glass Round Glass Discs: Soda-Lime Glass (CTE 9.0 x 10^-6 /K, 360 nm – 2.0 um); Diameter 2 – 450 mm, thickness 0.1 – 50 mm. Single-piece prototypes to production volumes, quoted from your drawing.

A drawing for soda-lime glass round glass discs is mostly a conversation about edges and datums. We produce them in Soda-Lime Glass at Diameter 2 – 450 mm, thickness 0.1 – 50 mm, with diameter +/-0.02 mm as the controlling tolerance, and finish the perimeter per spec.

The numbers

Material Soda-Lime Glass (Float per ASTM C1036, low-iron option)
Thermal expansion (CTE) 9.0 x 10^-6 /K
Service temperature 350 C continuous
Transmission range 360 nm – 2.0 um
Density 2.50 g/cm3
Knoop hardness 585 kg/mm2
Refractive index 1.52 @ 587 nm
Stock thickness 0.40 – 19 mm
Maximum blank size 1,000 x 800 mm
Geometry Round Glass Discs
Size envelope Diameter 2 – 450 mm, thickness 0.1 – 50 mm
Key tolerance diameter +/-0.02 mm
RFQ inputs PDF/DXF/STEP drawing, quantity brackets, surface and edge spec

Specification advice

Before sending the RFQ, check these against your drawing:

  • Material note: higher CTE means edge chips propagate under thermal load, so edge finishing quality drives reliability.
  • Hold the controlling dimension (diameter +/-0.02 mm) and let secondary dimensions carry standard tolerance – it is the single biggest cost lever.
  • Over-specification is the quiet budget killer: a 20/10 scratch-dig face costs roughly three times an 80/50 face, so grade each surface individually.

For the complete framework, see the tolerance design guide and the holes and edges design guide.

Capabilities and limits

One material, many routes: on Soda-Lime Glass we also quote coring, grinding, dicing, sandblasting, and multi-step drawings are the norm rather than the exception.

Production route: coring, cnc machining, edge grinding – selected per geometry and volume. Edge condition: entry/exit chamfer standard.

Where these parts end up

Orders for soda-lime glass round glass discs cluster in led packaging (groove covers, phosphor carriers, package windows); industrial displays (touch covers, gauge windows, printed bezels). Background reading on the underlying material science: ASTM C1036 flat glass standard.

The fastest route to a quote is geometry: use the 3D builder below, draw a dimensioned 2D drawing from it, or open the site-wide custom glass machining 3D + 2D builder for fully custom parts.

Related reading on this site: ITO coating process, high-temperature quartz windows, fused silica wafers 2-12 inch.

Common questions

What files do you need for a quote?

A dimensioned PDF plus DXF or STEP geometry. If only a sketch exists, our drawing review service formalizes it before quoting.

Do parts ship with inspection data?

Dimensional reports, surface certificates and material certs per melt are available; specify the level on the RFQ.

What tolerances are achievable on Soda-Lime Glass parts?

Ground features hold +/-0.01 mm and lapped thickness reaches +/-0.003 mm. Higher CTE means edge chips propagate under thermal load, so edge finishing quality drives reliability.

What thickness range do you stock for Soda-Lime Glass?

Standard stock spans 0.40 – 19 mm, with blanks up to 1,000 x 800 mm. Other formats are sourced per order.

Specifications on this page were last reviewed by our engineering team in October 2026.
